Sonnet Tech Echo Express SE I Thunderbolt 5 One-Slot PCIe Card Expansion System - Black

SKU: ECHO-EXP-SE1-T5 Barcode: 732311014314

Echo Express SE I Thunderbolt 5 One-Slot PCIe Card Expansion System Read more Read less

Qty.
Product Enquiry

Features

Adds Connectivity, Improves Capabilities
Connects a high-performance PCIe card to your computer with Thunderbolt ports.

Thunderbolt 5 to PCIe Device
Provides 6000 MB/s of bi-direction PCIe bandwidth to the installed card.

Broad PCIe Card Compatibility
PCIe 4.0 x8 card slot support one half-length+ (maximum 7.75 inches long), full-height, single-width PCIe card (plus one daughter card).

Pro Power
Auxiliary PCIe power connector for a power-hungry card; second Thunderbolt port provides 15W of power to the connected peripheral.

Compact. Lightweight. Amazing Performance.
Small footprint, but large enough to support nearly every Thunderbolt-compatible PCIe card at maximum performance.

Connect Additional Devices
One Thunderbolt port connects to computer; second port supports daisy-chaining additional Thunderbolt peripheral devices, or connection of a USB device.

Extremely Quiet
Temperature-controlled, variable-speed fan automatically and quietly cools the card.

Rugged Aluminum Housing
Provides robust and secure protection.

Smart Power Management
System powers on/off automatically with the computer; no power switch required.

Mac Compatible
Supports all M series Macs and Intel Macs with Thunderbolt 3 ports.

Windows Compatible
Supports Windows computers with Thunderbolt 5 or 4 ports, or USB4 ports.

Linux Compatible
Supports Linux computers withThunderbolt 5 or 4 ports, or USB4 ports.

Specifications

Form Factor

  • Thunderbolt desktop enclosure

External Connectors

  • Two Thunderbolt ports
  • 12V power port

Internal Connector

  • 6-pin Mini-Fit provides power for PCIe cards that require supplemental power

Expansion Slot

  • One x8 mechanical (x4 electrical) PCIe 4.0 [Thunderbolt 5 spec]

PCIe Card Supported

  • One half-length+ (maximum 7.75 inches long), single-width, full-height x8 PCIe card
  • One daughter card

Power Adapter

  • Universal 60W, 100-240V, 50-60 Hz
  • NRTL Certified

Operating Temperature

  • 0ºC to 35ºC (32ºF to 95ºF)

Dimensions (WxDxH)

  • 8.5 x 28.3 x 14.6 cm

Weight

  • 1.86 kg (Product)
  • 2.06 kg (Packaged)

Compliance

  • RoHS 3 (Directive 2015/863)
  • IEC62368-1 and IEC62368-2

Product Specifications

Colour Black
Range Echo Express
Manufacturer Sonnet
Compliance Thunderbolt
Warranty 24 Months
Weight 2.17
Series Thunderbolt 5
Box Contents

1 x Echo SE I T5 Thunderbolt 5 Expansion System
1 x Universal power adapter
1 x Region-specific power cable
1 x 6-pin to 6-pin auxiliary power cable
1 x 0.8- meter Thunderbolt 5 cable
1 x ThunderLok-A connector lock Documentation

Unleash the full potential of your computer with the Sonnet Echo SE I, the compact, single-slot Thunderbolt 5 to PCIe card expansion system.

Connect one high-performance PCIe card—like a video capture, audio interface, or 10Gb Ethernet card—to add the specialized connectivity your modern laptop or desktop lacks. The Thunderbolt 5 interface delivers a massive 6000 MB/s of bi-directional PCIe bandwidth, ensuring your pro card operates at maximum speed.

Featuring a second Thunderbolt port for daisy-chaining and ultra-quiet operation, the rugged aluminum enclosure is perfect for noise-sensitive workflows. Easily transform your Thunderbolt-equipped computer into a powerhouse!
